*Without Dryer
| PRODUCT CODE | 076R.00100.BD |
| DESCRIPTION | *Stainless steel body, boiler and washing tank *One-piece and rounded corner hygienic washing tank *Washing capacity of 100 baskets per hour (Basket dimensions 50cmx50cm) *Effective drying thanks to its high-powered fan *3 liters of water consumption for each washing period *Automatic and user-friendly control panel *Continuous washing with drying thanks to the conveyor system *Savings in energy, detergent and water consumption *Washing arms made of stainless steel *Height optimization with adjustable feet *Easy start; one-button water filling and heating for boilers and washing tanks *Electrical components and cabling systems comply with international standards and safety *The entire body is insulated and has IPX5 protection standard against water *Thermostatically controlled rinsing and washing temperatures for effective washing *Valve system that prevents the return of water in the machine to the installation *Washing water temperature 55-60°C (provided that the feed water is at least 2 bar and 50°C) *Rinsing water temperature 80-85°C (provided that the feed water is at least 2 bar and 50°C) *Right inlet table |
| TYPE | Electric |
| WIDTH (mm) | 1750 |
| DEPTH (mm) | 850 |
| HEIGHT (mm) | 1500 |
| NET WEIGHT (Kg) | 220 |
| GROSS WEIGHT (Kg) | 220 |
| VOLUME (m3) | 2.1 |
| CAPACITY | 1650 Plates/Hour |
| ELECTRIC POWER | 38 |
| VOLT | 400V - 3 NPE |
| FREQUENCY | 50 |
| HOT WATER PRESSURE | 2-4 bar |
| HOT WATER HARDNESS | 0-10 French Hardness |
| COLD WATER INLET DIAMETER | 3/4'' |
| COLD WATER PRESSURE | 2-4 bar |
| COLD WATER HARDNESS | 0-10 French Hardness |
| DRAIN INLET DIAMETER | Ø 50 |
| TANK VOLUME | 90 |
| BOILER VOLUME | 18 |
| WASH PUMP FLOW RATE | 659 |
| RINSE PUMP FLOW RATE | 18 |
| BOILER HEATER POWER | 27 |
| TANK HEATER POWER | 9 |
| WASH PUMP POWER | 1.5 |
| RINSE PUMP POWER | 0.37 |
| WASH WATER TEMPERATURE | 55 - 60 |
| RINSE WATER TEMPERATURE |
